Super Wide 15MM Double Rows 240LEDs DC24V White Color 2835 20W LED Strip
The 15mm width of our LED strip’s PCB and 240LEDs offers a larger optical surface, ensuring a more uniform illumination in various applications.
This enhanced width not only provides adaptability to special designs and shapes but also facilitates simpler installations.
Moreover, it accommodates more LEDs, resulting in higher brightness and impactful visual effects-ideal for scenarios such as exhibitions, billboards, or dynamic stage lighting.
Order Information:
Model NO. | Voltage | Power | LED Type | LED Qty | PCB Width | Beam Angle | CRI | CCT | Cut Unit | Lumen Output | Efficiency | Max Run |
TS15WXX-283527-24CV-240D | 24V | 20W | SMD2835 | 240 | 15mm | 120 | 80 | 2700K | 25mm | 1820lm | 91lm/W | 5M |
TS15WXX-283530-24CV-240D | 24V | 20W | SMD2835 | 240 | 15mm | 120 | 80 | 3000K | 25mm | 1820lm | 91lm/W | 5M |
TS15WXX-283540-24CV-240D | 24V | 20W | SMD2835 | 240 | 15mm | 120 | 80 | 4000K | 25mm | 1900lm | 95lm/W | 5M |
| TS15WXX-283560-24CV-240D | 24V | 20W | SMD2835 | 240 | 15mm | 120 | 80 | 6000K | 25mm | 1900lm | 95lm/W | 5M |
Technical Data:
